Lately, I've been looking for ways to detect faces in photos with PHP. Nowadays, face detection is built in many consumer products (camera obviously, but also Google and iPhoto), and seems to be a pretty common job. So I expected to find many solutions for doing it with PHP. Surprisingly, the only one I could find is OpenCV, an opensource lib that was originally developed by Intel. OpenCV seems to perform well but you need to be able to install it on your server. In my case, I wanted to have a pure PHP solution, so it can work with most hosts.
Learning about face detection
So I started to think about implementing it myself. I read a articles, scientific papers, etc. The website http://www.facedetection.com/ is a great resource by the way. From this short research, I learnt that one of the most popular solutions is to use Viola Jones training with a Haar classifier. Very informative, but tedious to implement. I'm lazy, you know.
Always look at what others are doing
Then I looked for existing implementations in other languages. Let's say Flash and Javascript. With Canvas, Javascript developers will certainly look at what flash developers do. There seem to be a few libs for face detection in AS3. They even work in real time. Pretty cool. I kept searching and finally found a canvas+javascript implementation of face detection at http://blog.kpicturebooth.com/?p=8.
The code looked fairly compact and simple. Shouldn't be hard to port to PHP.
The code
Once the code converted to PHP, here's the result:
<?php
//
// This program is free software; you can redistribute it and/or
// modify it under the terms of the GNU General Public License
// as published by the Free Software Foundation; either version 2
// of the License, or (at your option) any later version.
//
// This program is distributed in the hope that it will be useful,
// but WITHOUT ANY WARRANTY; without even the implied warranty of
// MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
// GNU General Public License for more details.
//
// You should have received a copy of the GNU General Public License
// along with this program; if not, write to the Free Software
// Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301, USA.
//
// @Author Karthik Tharavaad
// karthik_tharavaad@yahoo.com
// @Contributor Maurice Svay
// maurice@svay.Com
class Face_Detector {
protected $detection_data;
protected $canvas;
protected $face;
private $reduced_canvas;
public function __construct($detection_file = 'detection.dat') {
if (is_file($detection_file)) {
$this->detection_data = unserialize(file_get_contents($detection_file));
} else {
throw new Exception("Couldn't load detection data");
}
//$this->detection_data = json_decode(file_get_contents('data.js'));
}
public function face_detect($file) {
if (!is_file($file)) {
throw new Exception("Can not load $file");
}
$this->canvas = imagecreatefromjpeg($file);
$im_width = imagesx($this->canvas);
$im_height = imagesy($this->canvas);
//Resample before detection?
$ratio = 0;
$diff_width = 320 - $im_width;
$diff_height = 240 - $im_height;
if ($diff_width > $diff_height) {
$ratio = $im_width / 320;
} else {
$ratio = $im_height / 240;
}
if ($ratio != 0) {
$this->reduced_canvas = imagecreatetruecolor($im_width / $ratio, $im_height / $ratio);
imagecopyresampled($this->reduced_canvas, $this->canvas, 0, 0, 0, 0, $im_width / $ratio, $im_height / $ratio, $im_width, $im_height);
$stats = $this->get_img_stats($this->reduced_canvas);
$this->face = $this->do_detect_greedy_big_to_small($stats['ii'], $stats['ii2'], $stats['width'], $stats['height']);
$this->face['x'] *= $ratio;
$this->face['y'] *= $ratio;
$this->face['w'] *= $ratio;
} else {
$stats = $this->get_img_stats($this->canvas);
$this->face = $this->do_detect_greedy_big_to_small($stats['ii'], $stats['ii2'], $stats['width'], $stats['height']);
}
return ($this->face['w'] > 0);
}
public function toJpeg() {
$color = imagecolorallocate($this->canvas, 255, 0, 0); //red
imagerectangle($this->canvas, $this->face['x'], $this->face['y'], $this->face['x']+$this->face['w'], $this->face['y']+ $this->face['w'], $color);
header('Content-type: image/jpeg');
imagejpeg($this->canvas);
}
public function toJson() {
return "{'x':" . $this->face['x'] . ", 'y':" . $this->face['y'] . ", 'w':" . $this->face['w'] . "}";
}
public function getFace() {
return $this->face;
}
protected function get_img_stats($canvas){
$image_width = imagesx($canvas);
$image_height = imagesy($canvas);
$iis = $this->compute_ii($canvas, $image_width, $image_height);
return array(
'width' => $image_width,
'height' => $image_height,
'ii' => $iis['ii'],
'ii2' => $iis['ii2']
);
}
protected function compute_ii($canvas, $image_width, $image_height ){
$ii_w = $image_width+1;
$ii_h = $image_height+1;
$ii = array();
$ii2 = array();
for($i=0; $i<$ii_w; $i++ ){
$ii[$i] = 0;
$ii2[$i] = 0;
}
for($i=1; $i<$ii_w; $i++ ){
$ii[$i*$ii_w] = 0;
$ii2[$i*$ii_w] = 0;
$rowsum = 0;
$rowsum2 = 0;
for($j=1; $j<$ii_h; $j++ ){
$rgb = ImageColorAt($canvas, $j, $i);
$red = ($rgb >> 16) & 0xFF;
$green = ($rgb >> 8) & 0xFF;
$blue = $rgb & 0xFF;
$grey = ( 0.2989*$red + 0.587*$green + 0.114*$blue )>>0; // this is what matlab uses
$rowsum += $grey;
$rowsum2 += $grey*$grey;
$ii_above = ($i-1)*$ii_w + $j;
$ii_this = $i*$ii_w + $j;
$ii[$ii_this] = $ii[$ii_above] + $rowsum;
$ii2[$ii_this] = $ii2[$ii_above] + $rowsum2;
}
}
return array('ii'=>$ii, 'ii2' => $ii2);
}
protected function do_detect_greedy_big_to_small( $ii, $ii2, $width, $height ){
$s_w = $width/20.0;
$s_h = $height/20.0;
$start_scale = $s_h < $s_w ? $s_h : $s_w;
$scale_update = 1 / 1.2;
for($scale = $start_scale; $scale > 1; $scale *= $scale_update ){
$w = (20*$scale) >> 0;
$endx = $width - $w - 1;
$endy = $height - $w - 1;
$step = max( $scale, 2 ) >> 0;
$inv_area = 1 / ($w*$w);
for($y = 0; $y < $endy ; $y += $step ){
for($x = 0; $x < $endx ; $x += $step ){
$passed = $this->detect_on_sub_image( $x, $y, $scale, $ii, $ii2, $w, $width+1, $inv_area);
if( $passed ) {
return array('x'=>$x, 'y'=>$y, 'w'=>$w);
}
} // end x
} // end y
} // end scale
return null;
}
protected function detect_on_sub_image( $x, $y, $scale, $ii, $ii2, $w, $iiw, $inv_area){
$mean = ( $ii[($y+$w)*$iiw + $x + $w] + $ii[$y*$iiw+$x] - $ii[($y+$w)*$iiw+$x] - $ii[$y*$iiw+$x+$w] )*$inv_area;
$vnorm = ( $ii2[($y+$w)*$iiw + $x + $w] + $ii2[$y*$iiw+$x] - $ii2[($y+$w)*$iiw+$x] - $ii2[$y*$iiw+$x+$w] )*$inv_area - ($mean*$mean);
$vnorm = $vnorm > 1 ? sqrt($vnorm) : 1;
$passed = true;
for($i_stage = 0; $i_stage < count($this->detection_data); $i_stage++ ){
$stage = $this->detection_data[$i_stage];
$trees = $stage[0];
$stage_thresh = $stage[1];
$stage_sum = 0;
for($i_tree = 0; $i_tree < count($trees); $i_tree++ ){
$tree = $trees[$i_tree];
$current_node = $tree[0];
$tree_sum = 0;
while( $current_node != null ){
$vals = $current_node[0];
$node_thresh = $vals[0];
$leftval = $vals[1];
$rightval = $vals[2];
$leftidx = $vals[3];
$rightidx = $vals[4];
$rects = $current_node[1];
$rect_sum = 0;
for( $i_rect = 0; $i_rect < count($rects); $i_rect++ ){
$s = $scale;
$rect = $rects[$i_rect];
$rx = ($rect[0]*$s+$x)>>0;
$ry = ($rect[1]*$s+$y)>>0;
$rw = ($rect[2]*$s)>>0;
$rh = ($rect[3]*$s)>>0;
$wt = $rect[4];
$r_sum = ( $ii[($ry+$rh)*$iiw + $rx + $rw] + $ii[$ry*$iiw+$rx] - $ii[($ry+$rh)*$iiw+$rx] - $ii[$ry*$iiw+$rx+$rw] )*$wt;
$rect_sum += $r_sum;
}
$rect_sum *= $inv_area;
$current_node = null;
if( $rect_sum >= $node_thresh*$vnorm ){
if( $rightidx == -1 )
$tree_sum = $rightval;
else
$current_node = $tree[$rightidx];
} else {
if( $leftidx == -1 )
$tree_sum = $leftval;
else
$current_node = $tree[$leftidx];
}
}
$stage_sum += $tree_sum;
}
if( $stage_sum < $stage_thresh ){
return false;
}
}
return true;
}
}
And you simply use the class this way:
$detector = new Face_Detector('detection.dat');
$detector->face_detect('maurice_svay_150.jpg');
$detector->toJpeg();
Which gives the following result:
The code requires GD and is a bit slow but should work on most PHP servers. You'll also need the data file: http://svay.com/experiences/face-detection/detection.dat. Let me know if you have ideas for improving the code :)
Résumé en français
J'ai récemment cherché une solution pour faire de la détection de visage en PHP. Après avec écarté plusieurs solutions qui ne sont pas facilement utilisable sur la plupart des hébergeurs, j'ai finalement porté du code Javascript+Canvas vers PHP+GD. Le résultat une class PHP qui est un peu lente, mais qui fonctionne sur la plupart des serveurs PHP. Si vous avez des idées pour améliorer le code, n'hésitez-pas!
